ATO 500W Solar Grid Tie Inverter, 12V/24V/48V DC to 110V/ AC on Grid Inverter, Pure sine Wave Power Inverter (10.5V-30V DC Input)

Description

• Technical Specifications *Input Voltage: 12V/ 24V/ 48V DC, range: 10.5V-30V DC/ 20V-50V DC (optional); *Output Voltage : 120V AC, range: 90-140V AC
• Pure Sine WaveUse SPWM directly to make pure sine wave output
• MPPTHigh performance maximum power point tracking (MPPT), Directly connected to the solar panels (do not need to connect the battery)
• APLPower automatically locked (APL), make the output power more stable; Automatically adapt to different load power factor; Automatically shut down when the power output of a fault
• Customer First If you have any issue about the product or service, please don't hesitate to email us. We will answer you within 12h

High performance solar grid tie inverter is 500 watt AC output power with low price, 12 volt/ 24 volt DC voltage input to 110 volt/ 230 volt AC output, precise MPPT and APL functions are adopted. The on grid inverter automatically adjusts the solar panels of max output power, do not need to connect the battery.Parameter ListGrid tie inverter model ATO-GTI-500Recommend using solar panels 620 WattDC maximum input power 600 WattDC maximum voltage 50.2V DCDC voltage 12V/ 24V/ 48V DC, range: 10.5V-30V DC/ 20V-50V DCRecommend PV Vmpp 18V (10.5V-30V DC) / 28-40V (20V-50V DC)AC output power 500WAnti-voltage protection FuseAC standard voltage 110V, range: 90-140V AC (*Note: Inverter output is single phase (L, N, G) one hot line only)AC frequency range 55-63Hz/ 45-53HzTopology With transformer typeOutput current total harmonic distortion THDI<5%Phase differnce <1%Islanding protection VAC, FACOutput short circuit protection Current-limitingShow LEDInstallation Wall hangingCooling method FanStandby power consumption <2WNight power consumption <1WAmbient temperature range -25 to +60Waterproof grade IP23 (indoor type design)Electromagnetic compatibility EN50081.part1 EN50082.part1Power system disturbance EN61000-3-2 EN60950-1Network test DIN VDE 1026Certification CEWarranty period 12 monthsInverter net weight 1.3kgDimension (LxWxH) 210x165x57mm
